Dental Panoramic X-Ray Simulator Manikin Cone - Beam CT Phantom Head

Dental Phantom X-Ray Manikin
NP1446CS Dental X-Ray Simulator Adult Complete NP1446CS Dental X-Ray Simulator Adult Complete

Buyamag INC


Dental X-Ray panoramic diagnostic phantom head maxillofacial simulator is a standard of reference for diagnostic radiology of the Head. Includes detailed Anatomical Features and adjustable Tripod Stand, carrying Storage case.

Used For: The Phantom is designed to assist technical and clinical staff in the selection, monitoring, training and verification of scanning parameters common to most radiology procedures requiring fine Anatomical Details. The Head Model provides a consistent tool for researchers, clinicians and technologists. It is ideal for determining optimum system settings, commissioning new equipment, monitoring system performance and training in Dental X-Ray, Panoramic X-Ray, CT and Cone Beam CT procedures.

The phantom is constructed of proprietary tissue equivalent materials, and is made of Tissue Simulating resins that mimic the X-Ray attenuation properties of human tissue for both CT and therapy energy ranges (50 keV-25 MeV). The Model approximates the average Male Human Head in both size and structure. The phantom includes detailed 3D anthropomorphic anatomy including: Teeth, Brain, Bone, Larynx, Trachea, Sinus, Nasal Cavities. The bones contain both cortical and trabecular separation. The Teeth include distinct Dentine, Enamel and Root Structure including the Nerve. The Sinus Cavities are fully open.

The mouth mandible jaw of the phantom is slightly opened in permanent, fixed position, and can not be adjusted. The front teeth are vertically aligned to replicate correct positioning with a bite guide. Please note that an actual bite guide or sensor cannot be used, mandible in fixed position and not adjustable or positioned in this phantom.

Desirable Functions for Head Diagnostics, Dental Teeth X-Ray Training Model to simulate a Dental Patient, for practicing students in Dental Schools, Medical Colleges Setting. Manikin for teaching dental students, Promotes Procedural skills, experience in practicing performing Dental Oral, CT Panoramic X-Ray, CT and cone beam CT systems

The Head Phantom includes an adjustable Tripod Stand for positioning within a cone beam CT or panoramic X-ray system. Tripod Stand allows: accurate Phantom positioning. The included stand is adjustable in the x-y-z axes as well as allowing rotations about each of these axes. The head easily screws onto the stand and locks into place. Phantom Head Manikin for: Dental X-ray, Panoramic X-ray, CT and cone beam CT procedures, Test reconstruction techniques and algorithms for implant planning and maxillofacial reconstruction, Frankfurt plane identified to ensure proper alignment, Positioning stand with six degrees-of-freedom, Tissue Equivalent from 50 keV to 25 MeTissue Equivalent from 50 keV to 25 MeV, Phantom Carry Case, Phantom Size: 18 x 23 x 27cm, Phantom Weight: 6.4kg (14lb), Phantom Material: Epoxy Resin, Tripod Stand : - Included, Hard Carrying Storage Case: Included. Stand Weight: 3.2 kg ( 7 lb)

USA-Made every step in the production
